Protection coordination
Breaker, fuse, SPD and disconnect schedules are checked as one electrical system.
Eaton helps EPCs, developers and facility owners connect Batteries & Energy Storage Systems, BOS protection, Solar Inverters & Microinverters and EV charging assets into disciplined electrical architectures.
| Review Point | Eaton Guidance |
|---|---|
| Battery chemistry and runtime | LFP, UPS backup and commercial BESS duty cycles mapped to load profile and reserve margin. |
| Protection coordination | Breaker, fuse, SPD and isolation points verified against available fault current and site service voltage. |
| Monitoring interface | Gateway, metering and alarm points documented for facility BMS and O&M workflows. |
| Review Point | Eaton Guidance |
|---|---|
| Disconnect placement | AC and DC disconnect locations evaluated for code access, lockout practice and emergency serviceability. |
| Combiner and surge protection | String aggregation, SPD type and enclosure rating aligned to rooftop, ground mount or battery container conditions. |
| Transformer interface | Dry type and pad-mounted transformer scope coordinated with inverter output and utility interconnect requirements. |
| Review Point | Eaton Guidance |
|---|---|
| Inverter topology | Hybrid, string, microinverter and backup inverter selections compared against resilience and expansion targets. |
| Grid event response | Ride-through, transfer logic and protective settings prepared for jurisdictional review. |
| EV charging load | Depot or workplace charging profiles integrated with storage dispatch and service capacity planning. |
Breaker, fuse, SPD and disconnect schedules are checked as one electrical system.
Battery cabinets, UPS backup and inverter interfaces are mapped before site procurement.
Submittals include the operating assumptions utilities and AHJs normally request.
Panels, enclosures and field-replaceable devices are arranged for safe access.
Specification notes reference UL, IEC and regional practices without obscuring project details.
Monitoring points and maintenance intervals are selected to support renewable asset availability.
Reference notes for backup, peak shaving and microgrid storage scope.
Request fileDisconnect, combiner, SPD and transformer review fields for EPC teams.
Request fileOutline drawings, compliance notes and project data request templates.
Request fileEaton can review the storage, BOS and conversion scope while there is still time to correct the architecture.
